Fox Factory Performance Elite Series 2.0 RC Shocks Polaris RZR 4 800 2010-2014

Fox Factory Performance Elite Series 2.0 RC Shocks Polaris RZR 4 800

The Performance Elite series 2.0 shocks by FOX enhance UTV durability and adjustability with features like a 7/8” hard chromed shaft and a comprehensive seal pack, ensuring resilience in tough conditions and serviceability over time. These shocks allow for precise customization of shock damping through Dual Speed Compression (DSC) adjustability and wide-range rebound, alongside ride height tweaks via the preload collar. Their 2.0-inch aluminum bodies promote efficient heat dissipation and increase oil volume, leading to better damping control with high-flow pistons. The inclusion of a piggyback reservoir boosts oil capacity and incorporates an internal floating piston to keep the nitrogen charge and shock oil separate. For extreme conditions, the Bottom-out Control (BOC) mechanism enhances compression damping at the end of the travel, ensuring up to 30 percent increased damping force, making for a smoother ride and the ability to withstand tough impacts. Designed for utmost versatility and adaptability across any terrain, the FOX Performance Elite Series 2.0 shocks offer an exceptional upgrade to UTV or Side-by-Side ride dynamics with straightforward bolt-on installation.

Features:

• Sold as a pair
• Piggyback reservoir
• PTFE-lined spherical bearings
• 5/8” hard-chromed shaft
• 2.0” Kashima-coated aluminum body
• Race, dune/desert, and trail spring type
• Fully re-buildable and re-valvable
• Dual-Speed Compression (DSC)
• Wide-range rebound

Adjustments / Technical Information:

• Front Extended Length: 16.920
• Front Compressed Length: 11.300
• Front Travel: 5.620
• Rear Extended Length: 18.920
• Rear Compressed Length: 12.50
• Rear Travel: 6.42
• Top Mount: Eyelet
• Bottom Mount: Eyelet
• Reservoir: Piggyback

Note: Replaces Fox Factory Part Number: 885-08-057
