Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP 2020-2023

Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP

The Performance Elite Series 2.5 shocks by FOX are specially designed for UTVs and Side-by-Sides, offering robust adjustability and enhanced durability. These shocks feature a 7/8” hard chromed shaft and a seal pack that's built to withstand harsh conditions, ensuring longevity. With Dual Speed Compression (DSC) adjustments, riders can fine-tune shock damping to match their riding style and the terrain. The preload collar allows for ride height adjustments, optimizing vehicle traction. These shocks come with 2.5-inch diameter aluminum bodies that help dissipate heat more effectively and increase oil volume for improved damping control, thanks to FOX's race-developed high-flow pistons. An added piggyback reservoir increases oil capacity and uses an internal floating piston to keep the nitrogen charge and shock oil separate. Further enhancing performance, the Bottom-out Control (BOC) system provides additional compression damping during severe impacts, increasing damping force significantly in the final stages of travel. This design delivers a balanced ride, improving compliance with small bumps while still being capable of handling heavy impacts. FOX's Performance Elite Series 2.5 shocks are designed to transform your vehicle's dynamics with a straightforward bolt-on installation, allowing it to excel across various terrains.

Features:

• Sold as a pair
• Piggyback reservoir
• 7/8” hard-chromed shaft
• Redundant seal pack
• Dual-Speed Compression (DSC)
• 2.5” Aluminum body
• Bottom-out control (BOC)
• BOC increases damping force up to 30 percent through the final 25 percent of travel
• PTFE-lined spherical bearings
• Fully re-buildable and re-valvable
• Wide-range rebound

Adjustments / Technical Information:

• Front Extended Length: 27.50
• Front Compressed Length: 18.95
• Front Travel: 8.55
• Rear Extended Length: 39.00
• Rear Compressed Length: 25.45
• Rear Travel: 13.55
• Top Mount: Eyelet
• Bottom Mount: Eyelet
• Reservoir: Piggyback

Note: Replaces Fox Factory Part Number: N/A
