Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP 4 2020-2026

Fox Factory Performance Elite Series 2.5 RC Shocks Polaris RZR Pro XP 4

The Performance Elite Series 2.5 shocks from FOX are custom-made for UTV and Side-by-Side vehicles, designed to improve durability and offer extensive adjustability. These shocks enable riders to conquer diverse terrains with ease, featuring a 7/8” hard chromed shaft and a robust seal pack suited for extreme conditions. They come equipped with Dual Speed Compression (DSC) settings for fine-tuning damping to match both the terrain and individual riding styles. Riders can optimize traction with comprehensive rebound adjustments and adjust ride height using the preload collar. With 2.5-inch diameter aluminum bodies, these shocks effectively dissipate heat and enhance internal oil volume, leading to improved damping control via FOX’s advanced high-flow pistons. The addition of a piggyback reservoir increases oil capacity and incorporates an internal floating piston to maintain separation between the nitrogen charge and shock oil. The Bottom-out control (BOC) feature significantly increases compression damping during hard impacts, offering a smoother ride with superior small bump compliance and the resilience to absorb significant impacts. FOX's Performance Elite Series 2.5 shocks are engineered to transform your vehicle's dynamics with a simple bolt-on design, providing a tailored experience across any terrain.

Features:

• Sold as a pair
• Piggyback reservoir
• 7/8” hard-chromed shaft
• Redundant seal pack
• Dual-Speed Compression (DSC)
• 2.5” Aluminum body
• Bottom-out control (BOC)
• BOC increases damping force up to 30 percent through the final 25 percent of travel
• PTFE-lined spherical bearings
• Fully re-buildable and re-valvable
• Wide-range rebound

Adjustments / Technical Information:

• Front Extended Length: 27.50
• Front Compressed Length: 18.95
• Front Travel: 8.55
• Rear Extended Length: 39.00
• Rear Compressed Length: 25.45
• Rear Travel: 13.55
• Top Mount: Eyelet
• Bottom Mount: Eyelet
• Reservoir: Piggyback

Note: Replaces Fox Factory Part Number: N/A
