Fox Factory Performance Series 1.5 Coil-Over QS3 Shocks Honda Pioneer 700 2014-2024

Fox Factory Performance Series 1.5 Coil-Over QS3 Shocks Honda Pioneer 700

The Fox Factory Performance Series 1.5 Podium QS3 shock kit transforms the Honda Pioneer into a high-performance off-road vehicle, equipped with innovative technology to enhance handling and durability. This replacement kit for the stock shocks and springs introduces internal floating piston technology in piggyback reservoirs, ensuring consistent damping by preventing the mixing of gas and oil. Unlike the stock shocks designed for comfort, this kit balances a smooth ride with the resilience needed for high-speed off-road adventures through its combination of single-rate and progressive-rate springs. It also features a Quick Switch 3-position compression damping adjustment for easy adaptation to various terrains and conditions. Crafted with hard-anodized aluminum bodies and 5/8-inch hard chromed shafts, these shocks are built for both performance and longevity, offering a corrosion-resistant solution that's fully rebuildable for customized applications.

Features:

• Adjustments: spring preload
• Quick Switch 3-position compression (QS3)
• High-flow velocity-sensitive damping
• Internal Floating Piston (IFP)
• Ultra-durable bottom-out bumper
• Type III hard-anodized aluminum body and reservoir
• Standard or Heavy-Duty spring rate
• 5/8” hard-chromed shaft

Specifications:

• Front Extended Length:19.290
• Front Compressed Length:13.670
• Front Travel:5.620
• Rear Extended Length:18.270
• Rear Compressed Length:12.050
• Rear Travel:7.520
• Top Mount:Eyelet
• Bottom Mount:Eyelet
• Reservoir:Piggyback

Note: Replaces Fox Factory Part Number: 885-06-108
